Our engineering division designs drive-in systems in accordance with the principles set out in AS 4084:2023 (Steel Storage Racking). We provide complete structural engineering data packs, including material mill certificates, section properties, elastic modulus data, and second-order sway deflection calculations. This allows local Australian CPEng engineers or certifiers to verify the project on-site. In addition, customized AS 4084-compliant safe working load plaques indicating unit loads per level, maximum bay capacities, and inspection intervals are fabricated and supplied with the shipment.

Yes. For seismically active regions across New Zealand (such as Wellington, Canterbury, and Napier), our design team works directly from your site's seismic acceleration parameters ($C_h(T_1)$, subsoil class, and ductility factor $\mu$) under NZS 1170.5. Drive-In racking inherently lacks intermediate transverse horizontal beams, so seismic bracing requires reinforcement: heavy-gauge floor anchor footings, enlarged baseplates with chemical post-installed anchors, reinforced top-tie portal beams, and upgraded rear vertical K-bracing arrays to resist seismic loads without structural dislodgement.

Because forklifts enter the physical storage channels, clearance parameters require precise engineering. Standard designs provide a minimum clearance of 75mm to 100mm between the forklift chassis (or mast assembly) and the internal cantilever support arms. Pallet cantilever rails must maintain a minimum support landing flange width of 50mm on either side of the pallet bottom runner. Floor-mounted structural steel guide angles (typically $100 \times 100 \times 8 \text{ mm}$ or heavy floor guide rails) are anchored directly to the slab to prevent forklift steering drift inside deep channels.

Racking components shipped to Oceania or North America are packed using certified steel frames, structural steel stillages, or heat-treated timber that carries the international ISPM-15 IPPC stamp. This approach satisfies Australian Department of Agriculture, Fisheries and Forestry (DAFF) and New Zealand Ministry for Primary Industries (MPI) biosecurity import inspection protocols. This eliminates the risk of port delays, quarantine fumigation surcharges, or return-order penalties at container destination ports like Sydney, Melbourne, Brisbane, and Auckland.

For deep-freeze environments operating from -18°C to -35°C, standard commercial paint is prone to embrittlement, chipping, and micro-cracking due to thermal contraction. We recommend electrostatic epoxy-polyester hybrid powder coating baked at high temperature, with a cured dry-film thickness (DFT) of 70 to 90 microns. For harsh, condensation-heavy blast freezers or coastal sea air facilities, components can be supplied in pre-galvanized high-yield steel or hot-dip galvanized finishes meeting ISO 1461 standards (yielding 65 to 85 microns of zinc-iron metallurgical protection) for long-term corrosion resistance.

Our engineering team can return an engineered layout within 24 hours given five primary specifications: 1. Warehouse CAD floor plan indicating clear height to underside of purlins, light fixtures, and overhead fire sprinklers. 2. Pallet dimensions, including load overhang and total maximum weight per pallet unit. 3. Material handling equipment (MHE) specification sheet: forklift model, overall chassis width, mast collapsed height, and maximum lift height. 4. Concrete floor slab details: compressive strength ($f'_c$ in MPa), slab thickness, and reinforcement type. 5. SKU rotation profile: required number of lanes, depth per lane, and batch replenishment cycles.
