Fabricated from certified Q235B and Q355B cold-rolled structural steel. Every system features precision cold-punched adjustment pitches (50mm, 75mm, and 76.2mm teardrop patterns), robotic seam welding, and oven-cured electrostatic powder coatings conforming to AS 4084, FEM 10.2.02, and RMI standards.
European specification selective pallet rack engineered with heavy-gauge upright omega profiles. Provides 100% immediate selectivity for high-throughput fast-moving consumer goods (FMCG) and third-party logistics (3PL) fulfillment centers.
Mechanical crank-driven mobile shelving systems operating on precision-milled ground tracks. Designed for corporate archives, legal repositories, and high-density industrial parts storage with triple safety interlocks.
Boltless teardrop punched upright frames engineered for North American and South American distributors. Tool-free beam pin-locking mechanism allows rapid beam level reconfiguration without structural compromise.
Engineered for non-standard footprint warehouses, irregular column grids, and mixed-mode storage combining lower manual picking tiers with upper bulk reserve pallet storage.
Engineered corrugated pop-up display shelving for retail buffer zones, e-commerce promotional assembly, and secondary point-of-sale staging inside omni-channel retail distribution hubs.
Reinforced bolted frame configuration with multi-tier mesh or solid steel shelf decking. Engineered to integrate seamlessly with multi-level catwalk mezzanines for high-density automotive spare parts.
Aisle-free cantilever arm support design enabling forklift drive-through and deep-lane stacking. Eliminates wasted access corridors, boosting floor space volume utilization by up to 75% for cold stores.
Specialized cryogenic powder-coated structural steel racking engineered for cold logistics and refrigerated dairy facilities operating down to -35°C without embrittlement or surface micro-fissuring.
With over two decades of metallurgical research and structural racking engineering, Guangzhou Heda Shelves Co., Ltd. delivers institutional-grade storage systems with complete audit traceability and end-to-end quality assurance.
We procure certified prime hot-rolled and cold-rolled steel coils exclusively from premier state-owned mills (Baosteel and Shougang). Every batch is verified via EN 10204 3.1 Mill Test Certificates for strict chemical composition and yield strength limits (Q235B ≥ 235 MPa, Q355B ≥ 355 MPa).
Our factory houses 24 automated multi-station roll-forming lines paired with high-speed uncoilers and multi-hole CNC hydraulic punching stations. Beam end-connectors undergo multi-axis robotic MAG welding with automated seam inspection to eliminate cold laps.
All structures are audited and stamped under CE Certification No. 2435-CPR-8605159 and ISO 9001:2015 Management System No. 18624Q00169R0M. Our engineering designs reference Australian AS 4084, European EN 15512, and US RMI MH16.1 specifications.
Components undergo rigorous automated alkaline degreasing, ultrasonic rust removal, zinc-phosphating, and deionized water rinsing before entering a Swiss Gema electrostatic powder coating booth. The thermosetting epoxy-polyester coat (60–90 μm) ensures superior salt spray resistance.
Every export shipment is palletized onto heavy-duty steel stillages or ISPM-15 certified heat-treated timber dunage, specifically conforming to DAFF (Australia) and MPI (New Zealand) border quarantine standards. Bundled beams and nested uprights maximize 40HQ container volumetric capacity.
Within 24 hours of receiving your warehouse architectural drawings, our in-house structural engineering department generates full 3D CAD layout models, aisle clearance validations, seismic base plate calculations, and load plaque tables ready for local building certifier sign-off.
To avoid costly customs disputes, structural non-compliance, and warehouse safety audit failures, professional procurement teams must evaluate racking specifications across regional building codes.
| Design Parameter | Heda Shelves Engineering Baseline | Australian Standard (AS 4084:2023) | European Standard (EN 15512:2020) | American Standard (RMI ANSI MH16.1) |
|---|---|---|---|---|
| Primary Steel Grade | Certified Q235B / Q355B Cold-Rolled | AS/NZS 3678 / AS 1397 G350-G450 | EN 10025 S235JR / S355JR | ASTM A1011 / A36 / SS Grade 50 |
| Permissible Beam Deflection | 1/200 of Clear Span ($L/200$) | $L/200$ (Serviceability Limit) | $L/200$ (Max deflection limit) | $L/180$ (Nominal operating max) |
| Upright Pitch Adjustability | 50mm, 75mm, 76.2mm (Teardrop) | 76.2mm or 50mm Standard Pitch | 50mm or 75mm Metric Standard | 2.0-inch (50.8mm) Teardrop Universal |
| Beam End Connector Design | 3, 4, or 5-Finger Claw with Spring Safety Pin | Captive mechanical auto-locking pin | EN 15512 moment stiffness verified | Positive engagement lock pin (shear tested) |
| Seismic Design Modeling | Multi-modal dynamic response spectrum | AS 1170.4 & NZS 1170.5 Seismic Actions | Eurocode 8 (EN 1998-1) Criteria | ASCE 7 & IBC Seismic Zone Criteria |
| Corrosion Protection Testing | 500hr Salt Spray (ASTM B117) / HDG 1000hr+ | AS 4750 Electrostatic Powder Coat | EN ISO 12944 C2/C3 Durability | RMI Clean & Pretreatment Standard |
| Compliance Certification | CE No. 2435-CPR-8605159 | Engineering calculation dossier ready | ISO 9001:2015 Verified | Third-party mill test certs provided |
Macroeconomic shifts, automation integration, and regional nearshoring pressures are radically changing how corporate logistics procurement officers negotiate warehouse shelving contracts.
Autonomous Mobile Robots (AMRs) and Automated Guided Vehicles (AGVs) require tighter floor-level and beam-level installation tolerances. Procurement mandates are shifting from manual forklift tolerances (±5mm) to precision laser-guided tolerances (±1.5mm), forcing manufacturers to implement CNC automated punching and robotically milled upright base assemblies.
Escalating distributor markups in Western markets (often 40% to 70% above factory FOB) are driving 3PLs and general contractors toward factory-direct containerized procurement. Consolidating pallet racks, mesh decking, column guards, and cantilever arms into unified 40HQ containers dramatically lowers total landed cost per pallet location.
Global carbon tax frameworks and institutional ESG covenants are compelling warehouse developers to document Scope 3 embedded carbon. Procurement contracts increasingly specify scrap-fed Electric Arc Furnace (EAF) steel and solvent-free, heavy-metal-free thermosetting powder coatings compliant with EU RoHS and REACH mandates.
Global warehouse operators seek modular, reconfigurable racking designs capable of moving across multiple geographic facilities. Standardizing on dual-punched uprights (compatible with both teardrop safety lock pins and metric bolted box beams) offers maximum operational versatility across global branches.
Our Guangzhou R&D center continuously pioneers advancements in high-strength cold-formed metallurgy, smart warehouse telemetry, and ultra-durable finishing chemistry.
By transitioning from conventional Q235B to high-strength titanium-niobium micro-alloyed Q355B steel, we reduce upright section profile mass by up to 14% while expanding critical axial buckling load resistance. This optimizes ocean freight container weight limits without diminishing safety factors.
Next-generation rack installations feature integrated wireless strain gauges and accelerometer nodes embedded directly into critical upright base plates and aisle portal ties. These sensors stream structural deflection data directly to warehouse management software (WMS), alerting facility directors to dangerous forklift collisions.
For rapid-turnover frozen food supply chains, our polymer chemists have formulated cross-linked polyurethane-epoxy hybrid powder coats. These coatings retain extreme elasticity at temperatures as low as -40°C, preventing the micro-crazing and subsequent subsurface oxidation typical of standard polyester paints.
Engineered for high-risk seismic regions such as New Zealand, California, and Japan, our newly patented hysteretic energy-dissipating base plates absorb horizontal earthquake shear forces through controlled sacrificial deformation, protecting concrete slabs and preventing catastrophic progressive collapse.
Authoritative engineering, customs compliance, and supply chain answers to assist procurement managers in de-risking offshore racking procurement.
Q235B offers a minimum yield strength of 235 MPa and a tensile strength of 370–500 MPa, making it ideal for standard selective pallet racks and light-to-medium longspan shelving up to 6 meters in height. Q355B features a yield strength of ≥355 MPa and tensile strength of 470–630 MPa. We employ Q355B for high-bay warehouse systems (exceeding 8–15 meters), drive-in racking frames, and structural mezzanines where higher axial loads and severe bending moments demand superior column strength without excessive steel gauge thickness.
We supply a complete structural engineering dossier for every bespoke project. This pack includes 2D CAD layout drawings with certified flue clearances, 3D isometric models, section modulus calculations ($Z_x, Z_y$), moment of inertia values ($I_x, I_y$), connection rotational stiffness data ($C_d$), and steel mill chemical test certificates. Your domestic certified professional engineer (PE or CPEng) can easily audit and sign off on these documents to secure municipal building consent.
In accordance with EN 15512 and AS 4084 standards, our beams are engineered not to exceed a vertical deflection limit of 1/200th of the clear horizontal span ($L/200$) under maximum uniformly distributed load (UDL). For instance, a standard 2700mm beam rated for 3000kg per level will exhibit a maximum center deflection of less than 13.5mm at full capacity, recovering elastically without plastic deformation upon load removal.
Racking components are bundled with automated strapping using heavy-gauge PET straps over protective cardboard edge protectors. Upright frames are nested or flat-packed into modular bolted steel stillages designed for rapid forklift unloading. Box beams are packed face-to-face separated by EPE foam spacers to prevent friction scuffing during rough sea voyages. Heavy base plates and small fasteners are packed in wooden crates conforming to ISPM-15 export regulations.
Australia (DAFF) and New Zealand (MPI) enforce strict biosecurity rules to prevent bark beetle and fungal entry. We utilize all-steel stillages or certified fumigated/heat-treated solid wood packaging with clearly legible IPPC stamps. Every container is inspected and cleaned prior to stuffing, and official packing declarations, commercial invoices, and ChAFTA / NZ-China FTA Certificates of Origin are delivered promptly to simplify customs release.
Standard production lead time for a 1-to-5 container order (approx. 50–150 metric tons) is 15 to 20 working days following approved 3D CAD shop drawings. Ocean transit from major southern Chinese deep-water ports (Guangzhou / Shenzhen) typically takes 12–16 days to Australian east coast ports (Sydney/Melbourne), 18–22 days to Auckland/Tauranga, 18–24 days to US West Coast ports, and 28–35 days to European base ports (Rotterdam/Hamburg).
Yes. We maintain automated multi-color powder reclamation booths. While the global industrial standard is RAL 5015 / RAL 5005 Blue for upright frames and RAL 2004 Pure Orange / RAL 1028 Yellow for load beams, we can formulate any custom RAL or Pantone color code. We also offer high-visibility contrasting bands on column upright protectors and customized safety signage stenciling.
Forklift impacts represent over 90% of warehouse rack failures. We advise specifying heavy-gauge omega column wrap protectors, heavy wrap-around aisle end guards anchored with high-tensile wedge anchors, rear pallet safety stop bars, wire mesh anti-collapse backing screens for pedestrian aisles, and heavy galvanized wire mesh decking to prevent accidental pallet punch-through.
Submit your warehouse floor plans and storage requirements. Our structural engineering team will deliver a comprehensive 3D CAD proposal, load capacity matrix, and direct-factory quotation within 24 hours.
