China Factory Direct Sale Warehouse Storage Heavy Duty Teardrop Pallet Racking System
Product Description
Product Description
| Product Name | Best Selling Heavy Duty Warehouse Storage Selective Pallet Rack Racking System | ||
| Color | RAL system | Material | Q235B steel |
| Usage | Warehouse Storage | Certification | RMI / CE / ISO / TUV / AS4084-2012 |
| Size | Customer Size | Structure | Assembled Freely |
| Height | Maximum 12000mm | Capacity | Maximum 4500kg/level |
| Width | 1350mm - 3900mm | Thickness | 1.5mm - 3.0mm |
| Style | Heavy Duty Selective Shelf | Packing | Customers' Request |
| Brand | KINGMORE | Port | Nanjing / Shanghai |
Selective Pallet Racking is the simplest, most commonly used, and most economical storage system option. It offers the best solutions for warehouses with palletized products and a wide variety of goods. Kingmore’s extensive range of pallet racking components are tested to the highest international standards.
Features & Benefits
- Direct access to each pallet
- Easy to control stock, adaptable to any product volume, weight, or size
- Easy assembly and safe using
Component Diagram
Pallet rack mainly consists of upright frame, beam and related accessories, like upright protector, frame barrier, pallet support bar, pallet stop beam, loading panel etc. Pallet rack structure is simple, installation is easy, disassembly is convenient, full free goods access mode can be reached.
Kingmore Products Specifications
- High durable strength steel
- RAL color code / Galvanized both available
- Adjusted by 50mm / 50.8mm / 75mm / 76.2mm
- Rigid beam connectors
- Automatic welding machines
- High grade bolts & nuts
- Certification: RMI / CE / ISO / TUV / AS4084-2012
Packaging & Shipping
Main Products
Company Information
Frequently Asked Questions (FAQ)
What steel material is used for the teardrop pallet racking system?
Our heavy duty teardrop pallet racking systems are manufactured using high-durable strength Q235B steel to ensure maximal load capacity and structural safety.
What is the maximum height and load capacity per level?
The racking system can reach a maximum height of up to 12,000mm, with a maximum loading capacity of up to 4,500kg per level depending on customized specifications.
Which international safety standards are certified?
Kingmore racking systems are fully tested and certified under RMI, CE, ISO, TUV, and AS4084-2012 international quality standards.
Can the shelf height be adjusted freely?
Yes, the structure is designed to assemble freely. Beams can be adjusted vertically at pitch intervals of 50mm, 50.8mm, 75mm, or 76.2mm.
What color options and surface finishes are available?
We offer custom colors according to the RAL system via durable powder coating, as well as galvanized surface finishes upon request.
What main components are included in this selective racking system?
A standard system mainly consists of upright frames, beams, and optional accessories such as upright protectors, frame barriers, pallet support bars, pallet stop beams, and loading panels.
